3. OPERATION
20
1. When the RGB, DVI1 or DVI2 display appears, press the PIP key to show the
PIP selection window. The signal names appear with their customized name
(see section 2.3.2). The window closes automatically when there is no opera-
tion for five seconds.
2. Press the S or T key to select the VIDEO port required. [VIDEO1] (2 or 3) can
also be selected by pressing the PIP key continuously. When you select the [VIDEO1], [VID-
EO2] or [VIDEO3], the PIP window is displayed. To close the PIP window, select [OFF].
3. Press the W or X key to close the PIP selection window.
4. You can move the PIP window by pressing the arrow keys when the menu is closed. Press
and hold the arrow keys to move the PIP window quickly.
Note 1: To show the VIDEO1, VIDEO2 and VIDEO3 pictures alternately, set the cycle time (5 to
20 sec) with [PIP SW TIME] on the [OSD] menu. In this case, the above setting is invalid. See
section 2.3.1.
Note 2: You can adjust the size of the PIP window on the [VIDEO1] (2 or 3) menu(s). See
section 2.2.
3.6 SYSTEM Menu
You can set the brilliance control and clear the memory on the [SYSTEM] menu. Also, you can
check signal status, the program number and the elapsed time (total time since first use) on the
[SYSTEM] menu.
3.6.1 How to set the auto dimmer
The auto dimmer feature automatically adjusts the brilliance according to the ambient brightness
detected by the light sensor on the front panel. Also, you can select the intervals at which the bril-
liance is adjusted.
Note: Do not put any objects in front of the light sensor.
1. Press the MENU key to show the menu.
2. Press the X key to select [SYSTEM]. The message “Input Signal Searching Please Wait” is
displayed and then the [SYSTEM] menu shown in the figure below is displayed.
3. Press the T key to select [AUTO DIMMER].
4. Press the W or X key to select the adjustment interval.
5. Press the MENU key to close the menu.
• [OFF]: Disable this function. • [3]: Every minute
• [1]: Every two seconds • [4]: Every three minutes
• [2]: Every 30 seconds • [5]: Every five minutes
VIDEO1
VIDEO2
VIDEO3
OFF
Signal status, model type,
program number and
elapsed time
RGB DVI1 DVI2 VIDEO1 VIDEO2 VIDEO3 OSD SYSTEM
AUTO DIMMER
EXT BRILL CTRL
DEFAULT RESET
INFORMATION
RGB : 1280
*
1024 Fh : 80kHz Fv : 75Hz
DVI1 : 640
*
480 Fh : 31kHz Fv : 60Hz
DVI2 : NO SIGNAL
VIDEO1 : NTSC
VIDEO2 : PAL
VIDEO3 : NO SIGNAL
MODEL TYPE
: MU-152
PROGRAM NO. : XX.XX
ELAPSED TIME : 100000 hour
OFF
OFF
NO
(OFF, 1~5)
(OFF
/
DVI1
/
DVI2
/
USB)
