2. INTERPRETING THE DISPLAYS
2-8
Description of graph display indications (con't from previous page)
Item Description
Water temperature graph The water temperature graph may be turned on or off with TEMP
GRAPH in the DISP1 menu.
Mode marker The mode marker shows by color which tracking mode is in use.
Green: Ground tracking mode
Blue: Water tracking mode, nav mode
Background: Ship's peed error
Depth graph The depth graph displays depth data in graph form. If, in the water track-
ing mode, the depth is greater than the depth range no depth data is dis-
played. To graph depth from an external source, set DEPTH SOURCE
in the OTHER menu (sub menu in the installation menu) to EXTERNAL.
Trip distance marker The trip distance marker shows trip distance in one-mile increments, in
green and background color alternately as shown below.
Background
color
Green
1 mile
