SPECIFICATIONS

Cool w/ Electric Heat (208/230V)

Figure 201

Model PZE07K3SC PZE09K3SC PZE12K3SC PZE15K5SC

Power supply V-Ph-Hz 230/208V /60Hz 230/208V/60Hz 230/208V /60Hz 230/208V/60Hz

Power supply type

Single-phase power

supply

Single-phase power

supply

Single-phase power

supply

Single-phase power

supply

Cooling

Capacity Btu/h 7000/6800 9300/9100 12000/11800 14500/14300

Input W 585/565 800/785 1110/1090 1450/1430

EER Btu/h.W 12/12 11.6/11.6 10.8/10.8 10.0/10.0

Amps A 2.6/2.8 3.5/3.8 4.9/5.3 6.4/7.0

Electric heating

Capacity (230/208V) Btu/h 12000/10000 12000/10000 12000/10000 17000/13900

Power input

(230/208V)

W

3650/2990 3650/2990 3650/2990

5050/4135

Rated current

(230/208V)

A

15.9/14.3 15.9/14.3 15.9/14.3

21.9/19.8

Sensible Heat Ratio

89% 86.7% 76.5%

68.1%

Moisture

Removal pints/hr

0.69 1.37/1.69 2.32/2.56 4.29/4.44

MCA A 20 20 20 30

MOP

A

20 20 20 30

Power factor 0.93/0.95 0.97/0.98 0.99/0.98 0.99/0.98

Max. input consumption W 850 1050 1450 2050

Max. current A 3.9 5.3 8.0 11

Compressor

Compressor 39X142GA$54LY 39X192GD&5JLA 44X2623KTFJMZ 44X362KK&FJMD

Type Rotary Rotary Rotary Rotary

Brand RECHI RECHI RECHI RECHI

Capacity Btu/h 6050 ± 5 % 8470± 5 % 11565±5% 16150±5%

Input W 470 ± 5 % 650 ± 5 % 855 ±5% 1225 ±5%

Rated current(RLA) A 2.4 3.4 4.5 6.4

Locked rotor

Amp(LRA) A 13.4±10% 17.5±10% 23.9±10% 34.7±10%

Thermal protector °F 275±13(Built-in) 275±13(Built-in) 311±9(Built-in) 293±9(Built-in)

Capacitor uF 15 25 30 30

Refrigerant oil ml FW68DA 160ml FW68DA 180ml FW68DA 240ml FW68DA 320ml

Indoor fan

motor

Model YDK-25-4-1 YDK-25-4-1 YDK-25-4-1 YDK-25-4-1

Brand Li Feng Li Feng Li Feng Li Feng

Insulation class B B B B

Input W 60 60 70 70

Output W 25 25 25 25

Rated current A 0.3 0.3 0.4 0.4

Capacitor uF 2 2 2 2

Speed(hi/mi/lo) r/min 900/850 1000/850 1150/900 1150/900

Indoor air ﬂow (Hi/Lo) cfm 350/330 390/330 450/340 450/340

Indoor Fan Noise Level(230V) dBA 49/44 49/44 52/45 53/46

Indoor Fan Noise Level(208V) dBA 49/44 49/44 52/45 52/46

Indoor Fan Noise Level((230V) cooling

mode

dBA

53/51 52/50 54/52 54/50
