12

PB

Model PZE07K3SC PZE09K3SC PZE12K3SC PZE15K5SC

Indoor Fan Noise Level(208V) cooling

mode

dBA

52/50 52/50 54/51 53/50

Indoor sound level (sound pressure

level) (Fan mode) dB(A)±2 49/44 49/40 52/45 52/45

Outdoor fan

motor

Model YDK-55-4P2-4 YDK-55-4P2-4 YDK-AI-55-4P2 YDK-55-4P2-4

Brand chigo/KB chigo/KB chigo/KB chigo/KB

Insulation class A A A A

Safe class IPX4 IPX4 IPX4 IPX4

Input W 104 104 104 104

Output W 55 55 55 55

Rated current A 0.5 0.5 0.5 0.5

Capacitor uF 3 3 3 3

Speed r/min 1600 1600 1600 1600

Outdoor fan

material ABS+G15 ABS+G15 ABS+G15 ABS+G15

Type Axial ﬂow Axial ﬂow Axial ﬂow Axial ﬂow

Diameter in. 13 3/4 13 3/4 13 3/4 13 3/4

Height in. 4 1/8 4 1/8 4 1/8 4 1/8

Outdoor air

ﬂow cfm 706 706 706 706

Outdoor sound level(sound pressure

level )(Heating mode) dB(A)±2 67 67 66 66

Unit

Dimension(W*H*D) in. 42*21*16 42*21*16 42*21*16 42*21*16

Packing (W*H*D) in. 45*25*19 45*25*19 45*25*19 45*25*19

Net/Gross weight lbs 90/103 94/105 106/117 107/118

Charged refrigerant type oz 17.6 18.7 21.5 27.5

Throttle type Capillary Capillary Capillary Capillary

Design pressure PSI 493/232 493/232 493/232 493/232

Power Cord plug （LCDI-20A（（LCDI-20A（（LCDI-20A（（LCDI-30A（

Controller

Control panel;

(Optional: Remote

control /24V wired

control)

Control panel;

(Optional: Remote

control /24V wired

control)

Control panel;

(Optional: Remote

control /24V wired

control)

Control panel;

(Optional: Remote

control /24V wired

control)

Operation temp °F 60-90 60-90 60-90 60-90

Ambient temp cooling °F 53-114 53-114 53-114 53-114

Ambient temp hating °F 35-75 35-75 35-75 35-75

SPECIFICATIONS

Cool w/ Electric Heat (208/230V)

Figure 201
