INTRODUCTION

Product Features

DIGITAL DEFROST

THERMOSTAT

The PZ-Series uses a digital thermostat to accurately monitor the outdoor coil conditions to allow the

heat pump to run whenever conditions are correct. Running the PTAC in heat pump mode saves energy

and reduces operating costs. The digital thermostat allows maximization of heat pump run time.

INSTANT HEAT

HEAT PUMP MODE

Heat pump models will automatically run the electric heater to quickly bring the room up to temperature

when initially energized, then return to heat pump mode. This ensures that the room is brought up to

temperature quickly without the usual delay associated with heat pump units.

SEPARATE HE AT/COOL

FAN CYCLE

CONTROL

The owner may choose between fan cycling or fan continuous mode based on property preference. Fan

continuous mode is used to keep constant airflow circulation in the room during all times the unit is ‘ON’. Fan

cycle will conserve energy by only operating the fan while the compressor or electric heater is operating.

The

ability to set the fan cycling condition independently between heating and cooling mode will increase

user comfort by allowing the choice of only constantly circulating air in the summer or winter time (unlike

other PTAC brands that only allow one selection).

EMERGENCY

HEAT OVERRIDE

In the event of a compressor failure in heat pump mode, the compressor may be locked out to provide

heat through the resistance heater. This feature ensures that even in the unlikely event of a compressor

failure, the room temperature can be maintained until the compressor can be serviced.

CENTRAL DESK

CONTROL READY

All Friedrich digital PTACs have low voltage terminals ready to connect a central desk control energy

management system. Controlling the unit from a remote location like the front desk can reduce energy

usage and requires no additional accessories on the PTAC unit.

INDOOR COIL

FROST SENSOR

The frost sensor protects the compressor from damage in the event that airflow is reduced or low outdoor

temperatures cause the indoor coil to freeze. When the indoor coil reaches 33°F, the compressor is

disabled and the fan continues to operate based on demand. Once the coil temperature returns to 59°F,

the compressor returns to operation.

ULTRAQUIET

AIR SYSTEM

The PZ-Series units feature an indoor fan system design that reduces sound levels without lowering

airow or preventing proper air circulation.

HIGH EFFICIENCY

The Friedrich PTAC has been engineered so that all functional systems are optimized so that they work

together to deliver the highest possible performance.

DUAL MOTOR

The dual-motor design means that the indoor motor can run at slower speeds which reduces sound

levels indoors.

ROTARY COMPRESSOR

High efciency rotary compressors are used on all Friedrich PTACs to maximize durability and ef-

ciency.

ALUMINUM

ENDPLATES

Outdoor coil endplates made from Aluminum reduce corrosion on the outdoor coil common with other coil

designs.

TOP-MOUNTED

AIR FILTERS

All Friedrich PTAC return air filters feature an element that has proven to prevent mold and bacterial

growth in laboratory testing.PXFTB replacement filter kits feature the same agent. All filters are

washable, reusable and easily accessed from the top of the unit without the removal of the front cover.

FILTERED FRESH

AIR INTAKE

Friedrich PTAC units are capable of introducing up to 30 CFM of outside air into the conditioned space.

The outdoor air passes through a washable mesh screen to prevent debris from entering the airstream.

R-32 REFRIGERANT

Friedrich PTAC units use environmentally-friendly refrigerant.

BREAK-PROOF

CONTROL DOOR

GALVANIZED ZINC

WALL SLEEVE AND

BASE PAN

Galvanized zinc coated steel wall sleeve and steel base pan undergo an 11-step preparation

process,

are powder coated with a polyester finish and cured in an oven for exceptional durability.

GOLDFIN

TECHNOLOGY

Goldfin Technology protects the outdoor coil from harsh environments.

Break-proof control door design maintains the integrity of the unit.
