Remove the chassis

1. Remove the EntryGard™ Screws. (Refer to Figure 426)

2. Hold the cabinet stationary then carefully slide the unit out of

the sleeve. Make sure to fully support the unit. (Refer to Figure

417)

Install the Chassis

1. Carefully team lift the chassis and set it into the cabinet. (Refer

to Figure 427)

2. Slide the chassis into the cabinet

4. Reinstall the EntryGard™ screws.. (Refer to Figure 426)

WARNING

ELECTRIC SHOCK HAZARD

Disconnect power to the unit before

servicing. Failure to follow this warning

could result in serious injury or death.

Figure 427 (Remove Chassis)

Figure 426 (Remove Entry Gard Screws)

REMOVE AND INSTALL THE CHASSIS
