INSTRUCTIONS FOR USE
FUNCTION SWITCH
A B C D E
Fig. 8
A. Lighting
B. Ventilation mode. Open damper. Returns
to basic ventilation after 60 minutes.
C. Speed 1 on fan motor.
D. Speed 2 on fan motor.
E. Speed 3 on fan motor.
The damper and the alliance fan motor clo-
ses automatically after 60 minutes. You can
also return to basic mode by pressing the
active button once more.
It is a good idea to open the damper a short
while before and after cooking, in order to
avoid the spread of odours in the room. Ad-
just the speed of the fan depending on the
type of food you are preparing. Preferably
allow the fan to run on low speed for a whi-
le after cooking. If needed, also use the
fan's low speed when the oven is in use, or
after using the dishwasher.
CARE AND MAINTENANCE
Cleaning
The cooker hood should be cleaned with a
damp cloth and washing-up liquid. With nor-
mal usage, the filters must be cleaned at
least every other month. Clean more often
after intensive use.
Fig. 9
Remove the grease filters by opening the
snap retainer, Fig. 9 Handle the filters care-
fully, taking care not to bend them.
Soak the filter in a solution of warm water
and washing-up liquid. The filter can also be
washed in a dishwasher.
Refit the grease filters after cleaning, mak-
ing sure they snap firmly into place.
B
A
Fig. 10
The inside of the fan and the damper must
be cleaned at least twice a year. Wipe with
a damp cloth and washing-up liquid. The
damper is easiest to clean when it is open.
The impellers and the side grilles must be
cleaned at least twice a year.
The motor core is removed by first discon-
necting the contact on the side of the mo-
tor unit, Fig. 10A. Rotate the latches, Fig.
10B, that lock the motor core in place. Pull
the unit outwards so that it is freed from
the pins, and then downwards.
Attention!
The motor core should not be washed or
exposed to moisture!
14
