Technical data

EPCE-TB -45 -60

Ambient temperature [°C] 0…+50

Storage temperature [°C] –20…+60

Degree of protection IP40

Max. payload in horizontal

mounting position

[kg] 5 10

Max. payload in vertical

mounting position

[kg] 2.5 5

Max. feed force Fx (sum of all

piston rods)

1)2)

[N] 85 150

Max. force on external stops

during homing

[N] 97 186

Max. speed

[m/s] 0.44 0.6

Velocity "SpeedPress/

SpeedRef"

[m/s] 0.02 0.02

Max. acceleration/decelera-

tion

[m/s

] 9 9

Duty cycle [%] 100 (+30…+50°C:–2% per Kelvin)

Min. stop/end position dis-

tance

[mm] 0.5

Repetition accuracy [mm] ±0.05

Feed constant [mm/

rev]

32 32

Nominal voltage [VDC] 24

Logic current consumption

(logic, pin1)

[A] DIO operation: 0.1…0.3

IO-Link operation: 0.1…0.15

Load current consumption

(power, pin1)

[A] 3 5.3

IO-Link port class A

IO-Link protocol version Device V 1.1

Max. permitted forces and torques on the piston rod

Fy [N]

Transverse load on piston rod EPCE-TB

Fz [N]

Transverse load on piston rod EPCE-TB

Mx [Nm] 0 0

My [Nm] 0.4 1
