Festo — EPCE-TB — 2023-11d

Technical data

13 Replacement

1. Save the application parameters to the IO-Link master è"Integrated drive EMCS" instruction

manual

www.festo.com/sp.

2. Demount the drive system

14 Removal.

3. Mount the drive system

7Assembly.

4. Connect the drive system

8 Installation.

5. Commission the drive system

9 Commissioning.

6. Update the firmware è"Integrated drive EMCS" instruction manualèwww.festo.com/sp.

Check the current status of the application data è"Integrated drive EMCS" instruction

manual

www.festo.com/sp.

14 Removal

WARNING

Unexpected movement of components.

Injury due to impacts or crushing.

• Before working on the product, switch off the control and secure it to prevent it from being switched

back on accidentally.

WARNING

Risk of Injury due to Unexpected Movement of Components

For vertical or slanted mounting position: when power is off, moving parts can travel or fall uncon-

trolled into the lower end position.

• Bring moving parts of the product into a safe end position or secure them against falling.

Demounting drive system

1. Allow the product to cool down to room temperature.

Disconnect electrical installations.

Remove the mounted attachment component.

4. Remove the attached accessories.

5. Remove the mounting attachments.

6. Observe transport information

6 Transport.

Demount drive or integrated drive EMCS è Manual integrated drive EMCS.

15 Technical data

EPCE-TB -45 -60

Certificates, declaration of

conformity for EMCS-ST

www.festo.com/sp

Design Electric cylinder with toothed belt and integrated drive

Guide Plain-bearing guide

Mounting position Any
