Festo — EPCE-TB — 2023-11d

Malfunctions

Fault description Cause Remedy

Loud running noises or

vibrations or rough run-

ning of the cylinder

Torsional stresses

–

Install the cylinder free of tension. Make sure

that the contact surface is flat

7.3 Mounting

the cylinder.

–

Change the layout of the attachment compo-

nent (e.g.payload).

–

Align cylinder and attached guide element par-

allel to each other.

– Use external guide.

Resonant vibration of

the cylinder

Change the travel velocity.

Toothed belt wear

–

Contact local Festo Service.

–

Replace cylinder

www.festo.com/catalogue.

Insufficient lubrication

of the piston rod

Lubricate the piston rod

Tab. 13 Overview of

lubrication intervals and accessories.

Vibration at the piston

rod

Operation at the reso-

nance point of the cyl-

inder

–

Change the travel velocity.

–

Change the payload geometry.

Piston rod does not

move

Drive pinion slips

–

Contact local Festo Service.

–

Replace cylinder

www.festo.com/catalogue.

Loads too high Reduce forces and torques. Consider dynamics.

Toothed belt ripped

–

Contact local Festo Service.

–

Replace cylinder

www.festo.com/catalogue.

Operation at the lower

ambient temperature

limit

–

Reduce velocity or force

Idling torque too high Wear in the drivetrain

–

Contact local Festo Service.

–

Replace cylinder

www.festo.com/catalogue.

Tab. 15: Overview of fault clearance

12.2

Repair

Repair or maintenance of the product is not permissible.

–

Replace with an identical product

www.festo.com/spareparts.
