11
To change the routing, please do the following:
• Choosing an output: Use the SELECT pot to select one block of eight channels (one of
the rows).
• Choosing an input: now press MENU to select an input for this output. Use SELECT to
select an input (one of the columns).
• Repeat this process as desired.
Keep the MENU button pressed longer to exit this menu.
Main Menu – MADI SFP MX Option
The PULSE16 can be upgraded with an optical MADI SFP module, called “MADI SFP MX
Option”, and in fact turns your PULSE16 to a full featured PILSE16 MX. With this module
equipped all 16 x 16 channels can be used with up to 192kHz.
The PULSE16 MADI-Upgrade consists of two parts:
a) the Ferrofish MADI SFP module (available at your dealer)
b) paid unlock code from the Ferrofish webshop.
ONLY USE GENUINE FERROFISH MADI SFP MODULES.
MODULES FROM THIRD PARTY MANUFACTURERS ARE NOT SUPPORTED!
After installing the SFP module you need to purchase an upgrade license from the
Ferrofish webshop. After entering the correct unlock code in the screen shown, the
PULSE16 is permanently upgraded to an PULSE16 MX.
The MADI SFP module is available as a single-mode and a multi-mode version. Most
devices on the market use the multi-mode standard. The single-mode version is used for
distances longer then 2km. Please refer to the exact specifications of your other MADI
devices for more information.
