ENGLISH
ASPIRLIGHT HV
WALL-MOUNTING
To mount the unit on the wall, it is necessary to:
Position one of the two supplied brackets on the back of
the unit, positioning it as shown here in the figure;
Remove the 3 screws from the top fitting side rear panel
and place the bracket as shown here in the figure; Put the
screws back in to secure the bracket;
Secure the second supplied bracket to the wall using
suitable anchoring systems (plugs, threaded bars, ...) and
use a level to make sure it is level.
Take out the screws from the two bottom corners of the
rear panel and install the two brackets with adjustable
feet; Put the bracket clamping screws back in;
Position the unit, using an upwards movement to couple
the two brackets, the one on the wall with the one installed
on the back of the unit;
Now adjust the bottom feet, to place the unit on the same
level as the wall or with a slight slope towards the wall
(1-2%) to facilitate vertical discharging;
Provide enough space to perform maintenance activities:
it must be possible to open the front cover of the unit;
Do not install the unit with the sides directly touching the
walls to avoid possible noise from contact, insert rubber
or neoprene strips in that case.
