9

ENGLISH

ASPIRLIGHT HV

2.2 UNIT POSITIONING

CEILING INSTALLATION

To mount the unit on the ceiling, it is necessary to:

Position the 2 mounting brackets on the perimeter sides of the unit where the air inlets are;

Remove the 3 screws from the fitting side panel and place the bracket as shown here in the figure; put the screws

back in to secure the bracket;

Anchor the unit to the ceiling, by the brackets, using suitable anchoring systems (plugs, threaded bars, chains...)

and use a level to make sure it is level.

Provide enough space to perform maintenance activities: it must be possible to open the cover of the unit (from

below).

Do not install the unit with the sides directly touching the walls to avoid possible noise from contact, insert rubber

or neoprene strips in that case.
