ENGLISH

USE OF MECHANICAL PUSH BUTTON CONTROL PANEL

OFF1 23

Light button

Press this button to turn the hood light on (button pressed in) or o

(button out)

Button 1:

Press this button (button in) to start or set the motor at min-

imum speed

Button 2:

Press this button (button in) to start or set the motor at me-

dium speed

OFF

OFF button

Press this button to switch the motor o

Button 3: Press this button (button in) to start or set the motor at max-

imum speed

USE OF ELECTRONIC PUSH BUTTON CONTROL PANEL

Timer/Filters alarm

Pressing the key with the motor active at any speed activates the Timer

function: this function determines the auto switch-o of the hood

after 15 minutes of operation. Activation of the function is signalled

by a RED ashing light.

With the Timer function active, the hood can still be switched o by

the user at any time by pressing the key

: the function will be auto-

matically disabled and the RED light will turn o. Should the speed be

changed with the Timer function active, the latter will be automatically

disabled.

On the other hand, ignition of the

xed RED light indicates a grease

lter alarm: this alarm noties that it is time to wash the metal an-

ti-grease lters (the alarm is triggered after approximately 30 hours of

use). After cleaning the lters, disable the alarm and reset the counters

by keeping the key pressed for 3 seconds.

To disassemble and assemble the anti-grease metal lters, re-

fer to the instructions on drawing

on page 6.

Mode button (ON/OFF)

Pressing the key switches on (or o) the hood motor: it starts at the

previously selected speed prior to switching it o (desired speed func-

tion). Should you wish to use a dierent speed, set if by using the +

and - keys.

Button +

By pressing the key, the motor speed increases. Speeds 1, 2 and 3 are

displayed by the number of LEDs switched on, excluding the light and

timer LEDs.

The + key in the version with 4 speeds has an intermittent light: the

4th speed or intensity is timed and after approximately 7 minutes the

motor automatically switches to 3rd speed.

Button -

By pressing the key, the motor speed reduces. Speeds 1, 2 and 3 are

displayed by the number of LEDs switched on, excluding the light and

timer LEDs.

Light button

ON: light on (lit button) OFF: light o

LIGHTING

The range hood is equipped with high eciency, low consumption LED spotlights with extremely long duration under normal use con-

ditions.

Should the LED spotlight need to be replaced, proceed as shown in the gure I on page 6.

MAINTENANCE

Before cleaning or carrying out maintenance operations, disconnect the equipment by removing the plug or switching o the main switch.

Regular maintenance guarantees proper operation and good performance over time.

Special attention is to be paid to the metal anti-grease lters and active carbon lters. In fact, frequent cleaning of the lters and their supports ensures that

no grease is accumulated on the hood, which is dangerous and can cause res.

EXTERNAL CLEANING

You are advised to clean the external surfaces of the hood

at least once every 15 days

to prevent oily substances and grease from sticking to them.

To clean the brushed stainless steel hood, the Manufacturer recommends using "Magic Steel" wipes. Alternatively, it can be cleaned using a damp cloth, slightly mois-

tened with neutral, liquid detergent or denatured alcohol. Finish o cleaning by rinsing well and drying with soft cloths.

Do not use too much water next to the push button control panel and lighting devices in order to prevent humidity from reaching electronic

parts. You must not use detergents containing abrasive, acid or corrosive substances or abrasive cloths: a direct consequence of not complying

with these warnings will result in irreversible deterioration of the hood's surface.

The Manufacturer declines all responsibility for failure to comply with these instructions.
