30
COOKER HOOD
FUMES DISCHARGE
EXTERNAL EXHAUST HOOD SUCTION
In this version the fumes and vapours are discharged outside
through the exhaust pipe.
To this end, the hood outlet fitting must be connected via a
pipe, to an external output.
The outlet pipe must have:
• a diameter not less than that of the hood fitting.
• a slight slope downwards (drop) in the horizontal sections to prevent con-
densation from flowing back into the motor.
• the minimum required number of bends.
• the minimum required length to avoid vibrations and reduce the suction
performance of the hood.
• You are required to insulate the pipes if it passes through cold environ-
ments.
Deviation for Germany:
when the kitchen hood is used at the same time as appliances that are powered by
energy other than electricity, the negative pressure in the room must not exceed 4 Pa
(4 x 10-5 bar).
HOOD WITH INTERNAL RECIRCULATION FILTERING
In this model, the air passes through the Carbon-Zeo (option-
al) filters to be purified and recycled in the environment.
Ensure that the Carbon-Zeo filters are assembled into the
hood, if not, install them as indicated in the assembly instruc-
tions.
ASSEMBLY INSTRUCTIONS
only intended for qualied personnel
The hood can be installed in various congurations.
The generic assembly steps apply to all installations; for each case,
follow the specic steps provided for the required installation.
OPERATION
WHEN TO TURN ON THE HOOD?
Switch on the hood at least one minute before starting to cook to direct fumes
and vapours towards the suction surface.
After cooking, leave the hood operating until complete extraction of all vapours
and odours. By means of the Timer function, it is possible to set auto switch-off
function which will allow the hood to turn off automatically after 15 minutes of
operation.
WHICH SPEED IS TO BE SELECTED?
speed (1-3): maintains the circulation of clean air with low electricity consump-
tion.
speed (4-5): normal conditions of use.
speed (6-7): presence of strong odours and vapours.
speed (8-P): rapid disposal of odours and vapours.
With a view to reducing environmental impact, it is suggested to always set the
minimum speed suitable for the required suction level.
WHEN SHOULD THE FILTERS BE WASHED OR REPLACED?
The metal filters must be cleaned every 30 hours of operation.
For further details see the “MAINTENANCE” chap.
HOOD TOUCH PUSHBUTTON PANEL
ON/OFF
Short pulse: Hood switch ON/OFF
Long pulse: Hood operation automatic cycle activation (A) accor-
ding to plate power.
Speed increase from 1 to…9 (up to “P”).
Speed “P”: active only for a few minutes, then speed 9.
Speed decrease from P to 1.
With hood active (short pulse): TIMER (flashing red LED)
Automatic switch-o after 15 min.
The function is disabled (red LED OFF) if:
- The motor is switched o (button
).
- Press the TIMER button
again .
With the hood OFF (long pulse 4s):
opening the fins for hood and filter maintenance
CARBON.ZEO FILTER ALARM
Maintenance after approximately 2000 hours of operation.
The display shows
alternating with the hood speed.
To reset the alarm: with the motor running, press the key
for 5 seconds.
The display shows
for 2 seconds.
To activate the alarm:
With the hood off, press the and keys for 5 seconds
The display shows .
Press the
key to activate the alarm, the display shows
with the dot in the top left-hand corner flashing.
Wait 3 seconds, the configuration is saved
To deactivate the alarm:
With the hood off, press the and keys for 5 seconds,
The display shows
.
Press the
key to deactivate the alarm, the display shows
with the dot in the top left-hand corner switched off.
Wait 3 seconds, the configuration is saved.
If the pushbutton panel is completely inactive, before contacting
the Technical assistance service, disconnect power temporarily to
the appliance (about 5“), possibly by acting on the main switch, to
restore normal operation. If this measure has no eect, contact the Techni-
cal assistance service.
OPERATION AND
USE OF THE COOKTOP
ONLY USE COOKWARE SUITABLE FOR INDUCTION HOBS.
When a cooking are is turned on, the bottom of the saucepan heats.
The cooking area only heats thanks to the heat given by the saucepan.
The cooktop automatically detects the size of the saucepan.
The heating power is to be chosen based on what shall be cooked.
With a view to reducing environmental impact, it is suggested to always set
the minimum power level suitable for the required cooking.
Please nd below a short table:
SETTING AREAS
1 - 2
Melt
Heat
Sauces, butter, chocolate,
gelatine
Precooked dishes
