ENGLISH
PRODUCT DATA SHEET
BRERA 75 COOKTOP
Product information according to Regulation (EU) Nr. 66/2014
Manufacturer Falmec S.p.a.
Model identication Brera 75
Type of hob Glass ceramic cooktop
Number of cooking zones /
cooking areas
4
Heating technology
Induction cooking zones and
cooking surfaces
SIZE OF USABLE SURFACE
9 Power Level:
2.1 kW
Booster (P):
3 kW
9 Power Level:
2.1 kW
Booster (P):
3 kW
BRIDGE
9 Power Level: 3 kW
Booster (P): 3,7 kW
9 Power Level:
2.1 kW
Booster (P):
3 kW
9 Power Level:
2.1 kW
Booster (P):
3 kW
9 Power Level:
1.4 kW
Booster (P):
2.1 kW
9 Power Level:
1.4 kW
Booster (P):
2.1 kW
190ø175
ø175
387
210210
TOTAL POWER: 2,8 - 7,4 kW
ENERGY CONSUMPTION (Wh / Kg)
Energy consumption cooking zones:
1
2
34
1: 187,2 Wh/Kg
2: 182,3 Wh/Kg
3: 188,5 Wh/Kg
4: 188,5 Wh/Kg
Energy consumption of the hob:
186,6 Wh/Kg
INSTALLATION
only intended for qualied personnel
Before installing the hood, carefully read the chapter 'SAFETY
INSTRUCTIONS AND WARNINGS'.
TECHNICAL FEATURES
The technical specifications are exhibited on the labels located inside the hood.
SAFETY INSTRUCTIONS FOR ASSEMBLY
Install the cooker after installing kitchen cabinets and basis.
Make sure that worktops have been veneered with thermoresistant glue in order
not to suffer deflections or detachments.
POSITIONING
Do not install the hood outdoors and do not expose it to outdoor environment
(rain, wind, etc.).
It is forbidden to install the appliance on fridges or freezers, wash-
ing machines, dishwashers, or tumble driers.
COOKER
ELECTRICAL CONNECTION
(only intended for qualied personnel)
Disconnect the equipment from mains power network before car-
rying out any operation on the cooker.
Make sure that electric wires inside the cooker are not disconnect-
ed or cut:
in the event of damage, contact your nearest Servicing Department.
Refer to qualied personnel for electrical connections.
Connection must be carried out in compliance with the provisions of law
in force.
Before connecting the cooker to the mains power network, check that:
• the mains voltage corresponds with the voltage indicated on the data
plate located inside the cooker;
• the electrical system is compliant and can withstand the load (see the
technical specifications located inside the cooker);
• the power supply plug and cable do not come into contact with temper-
atures exceeding 70 °C;
• the power supply system is effectively and properly connected to earth in
compliance with regulations in force.
• the socket used to connect the cooker is within reach.
In case of:
• devices fitted with cables without a plug: the type of plug to use is a
''standardised'' one. The wires must be connected as follows: yellow-green
for earthing, blue for neutral and brown for the phase. The plug must be
connected to an adequate safety socket.
• fixed equipment not provided with a power supply cable and plug, or any
other device that ensures disconnection from the electrical mains, with an
opening gap of the contacts that enables total disconnection in overvolt-
age category III conditions.
• Said disconnection devices must be provided in the mains power
supply in compliance with installation regulations.
The yellow/green earth cable must not be cut off by the switch.
The Manufacturer declines all responsibility for failure to comply with the safety
regulations.
Connection of the cooker
network Connection Cable sec-
tion
Power
cable
220V - 240V~ 50/60Hz 1P+N / 2P 3 x 4 mm²
H 05 VV - F
H 05 RR - F
380V - 415V~ 50/60Hz 2P+N 4 x 1.5 mm²
H 05 VV - F
H 05 RR - F
380V - 415V~ 50/60Hz 3P+N 5 x 1.5 mm²
H 05 VV - F
H 05 RR - F
