Rear Panels
See the descriptions on the next page for information on each rear panel connector. See
Wiring the Rear Panel Connectors on page 12 for connection information.
MLC 55 RS
AA
BB
MLC 55 RS VC
BB
CC
AA
BB
AA
MLC 55 RS MK
AA
BB
MLC 55 RS EU
COM/IR
POWER
12V
0.1 A MAX
GTx S
B
A
MLC 55 RS EU V
A
Control port
B
Power connector
C
Volume control connector (MLC 55 RS VC only)
Figure 8. MLC 55 Series Rear Panels
NOTE: The MLC 55 RS EU V rear panel has a black cover over the board, permitting
access to only the COM/IR RS-232 and Power connectors.
FIG_Rear panels
MLC 55 Series MediaLink Controllers • Installation and Operation 11
