Command and Response Table for Transmitter SIS Commands (continued)
FOXBOX Tx/Rx HDMI • Remote Control 23
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Status requests
View link 1 (Tx-to-Rx) status
1S
X1@]
View link 2 (Rx-to-Tx) status
2S
X1@]
View input video status
3S
X1@]
View input audio status
4S
X1@]
View all signal status
5S
SigI
X1@
•
SigO
X1@
•
HdcpI
X1@
•
HdcpO
X1@]
Report the status of the HDMI input,
HDMI output, HDCP encoding on the
input, and HDCP encoding on the
output.
View HDMI signal status
6S
SigI
X1@
•
SigO
X1@]
Report the status of the HDMI input
and HDMI output (always -- for a
transmitter).
View HDCP status
7S
HdcpI
X1@
•
HdcpO
X1@]
Report the status of the HDCP
encoding on the input and HDCP
encoding on the output.
View temperature
20S
X1#
F
•
X1#
C
]
Show temperature in degrees
Fahrenheit and Celsius.
Information requests
Information request
I
1Lnk
X1@
•
2Lnk
X1@
•
Vid
X1@
•
Aud
X1@
•
X1$
•
Tx
]
The unit responds with the current
status (signal detected) of optical
link 1, optical link 2, the video input,
and the audio link; the fiber optic
transmission mode (singlemode or
multimode); and the device type (Tx).
Show firmware version
Q
X1%]
Example:
Q
1.23
]
The factory-installed firmware version
is 1.23 (sample value only).
Request part number
N
60–nnnn–nn
]
Input sync detection
1LS
X1&
horizontal
,
X1&
vertical
]
Shows horizontal frequency in kHz and
vertical freq in Hz. 000.0,000.0 if no
signal is detected.
Resets
Reset audio
E
ZA
}
Zpa
]
Reset audio setting to default levels
(0 dB gain).
System reset
E
ZXXX
}
Zpx
]
Reset all settings to factory defaults.
KEY:
X1@
= Link and input status 0 = link or input not detected 1 = link or input detected
X1#
= Internal temperature nnnF•nnC
X1$
= Transmission mode SM = singlemode MM = multimode
X1%
= Firmware version v.vv
X1&
= Sync frequency xxx.xx (frequency in kHz [H] or Hz [V])
