Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Status Request
View link 1 Status
1S
X#]
Displays link 1 status (
X#
)
0 = active signal absent
1 = active signal present
View link 2 Status
2S
X#]
Displays link 2 status
View input video status
3S
X#]
Displays input video status
View input audio status
4S
X#]
Displays input audio status
View internal temperature
20S
X1$]
Displays internal temperature in
degrees F
Factory Defaults
System Reset (factory default)
E
ZXXX
}
Zpx
]
Resets unit to all factory default
values
Reset audio settings
E
ZA
}
Zpa
]
Resets all audio settings to factory
default values
Reset presets
E
ZG
}
Zpg
]
Rests all memory presets to factory
default values
SIS Command Validity Table
If only one fiber optic channel is enabled, the ability to configure the system through SIS
commands is limited by the lack of return communication from the receiver to the transmitter.
All commands issued through the transmitter are valid because link 1 allows signals to be
forwarded to the receiver. However, responses to queries originating from the transmitter about
the status of the receiver return invalid data.
All configuration of the receiver by commands issued through the receiver is valid. Attempts to
configure the the transmitter through the receiver in the absence of link 2 are invalid.
The following table shows the validity of commands issued through the receiver when only link 1
is active:
Adjustment
Color Valid
Tint Valid
Brightness Valid
Contrast Valid
Audio gain/attenuation
Invalid
Audio mute Valid
Audio output level Valid
Output configuration Valid
Input configuration
Invalid
Daisy chain mode Valid
Test pattern Valid
Video mute Valid
FOX Tx/Rx AV • Configuration 19
