Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Auto Image
Trigger
55*2#
]
Returns video adjustments (color,
contrast, tint, and brightness) to
default values (64).
Test Pattern
Color bars
1J
Tst1
]
Sets color bars test pattern on (
X(
).
0 = test pattern off 1 = color bars
2 = grayscale 3 = alternating pixels
Grayscale
2J
Tst2
]
Sets grayscale test pattern on.
Alternating pixels
3J
Tst3
]
Sets alternating pixels test pattern on.
Off
0J
Tst0
]
Sets test pattern off.
View current test pattern status
J
X(]
Displays current test pattern status.
Link #2 Transmission
Disable
66*0*0#
Rle*0*0
]
Disables link #2. Link #2 status (
X1)
):
0 = disables link #2 (receiver to
transmitter).
1 = enables link #2.
2 = enables receiver daisy chain
mode.
Enable
66*0*1#
Rle*0*1
]
Enables link #2.
Daisy chain
66*0*2#
Rle*0*2
]
Enables receiver daisy chain mode.
View current link #2 status
66*0#
0*
X1)]
Displays current link #2 status.
This command is only available on the
reciever unit; the transmitter responds
with an E14 error code.
Information Request
General information
I
1Link
X#
•2Link
X#
•Vid
X#
•Aud
X#
•
X1!
•
X1@]
X#
Link #1: active signal present (1)
or absent (0) •
X#
Link #2: active signal present (1)
or absent (0) •
X#
video output signal enabled (1) or
disabled (0) •
X#
audio signal enabled (1) or
disabled (0) •
X1!
SM or MM •
X1@
Tx or Rx
Query firmware (F/W) version
Q
x.xx
]
Displays current F/W version.
Query all F/W versions
0Q
x.xx-x.xx-x.xx-x.xx
]
Diplays information about all F/W
versions.
Query Factory F/W version
32Q
x.xx
]
Displays factory loaded F/W version.
Query updated F/W version
34Q
x.xx
]
Displays updated F/W version.
Query factory FPGA version
33Q
x.xx
]
Displays factory loaded Field
Programable Gate Array (FPGA)
version.
Query updated FPGA version
35Q
x.xx
]
Displays updated FPGA version.
Query part number
N
60-941-zz
]
Displays the unit part number.
Query other unit part number
1N
60-941-zz
]
Displays the part number of other
connected box.
FOX Tx/Rx AV • Configuration 18
