8S RS232/422/485 PCI/PCIe Expansion Module
6
Please note that this product does NOT support hot-plug feature by
means of the DB44 Expansion Cable. You can NOT connect or disconnect the
expansion cable unless you power off your system first.
1. Turn OFF the system power, remove the chassis cover from your computer
2. Locate an unused PCI slot for the PCI Host Adapter or PCI Express slot for PCIe
Host Adapter, remove the corresponding slot cover from computer chassis.
3. Plug the PCI or PCIe add-in Host Adapter in the slot, attached its card bracket to
the computer chassis screw. Put the chassis cover back on the computer.
4. Installing the Wall Mounting Brackets or antislip rubber bumpers if required:
5. Install the DB44 Cable from the PCI (or PCIe) Host Adapter card to the Module
box.
Warning!! Since the Expansion Cable’s connector carries proprietary
signals but with the same form factor as the standard DB44 connector, please do
NOT connect the Expansion Box nor the Host Adapter to other products.
Improper connection may damage the Expansion Module or the Host Adapter.
6. The Module Box is powered by the DB44 cable from the PCI or PCIe Host
Adapter. It requires you to connect a power cable from your system power supply
to your Host Adapter, you can choose the 15-pin SATA power connector type or
large 4-pin connector type cable, but don’t install both simultaneously.
5. Installing the Expansion Module Box
