Exquisit KGC231-60-E-050CB handleiding
Handleiding
Je bekijkt pagina 45 van 118
CLIMATE CLASS
TEMPERATURE RANGE
(SN) Extended temperature range
+10 °C to +32 °C
(N) Temperature range
+16 °C to +32 °C
(ST) Subtropical temperature range
+16 °C to +38 °C
(T) Tropical temperature range
+16 °C to +43 °C
Minimum clearances for ventilation
Air circulation at the rear, side and top of the appliance influences energy consumption
and refrigerating/freezing performance (depending on model). It is essential that the
minimum clearances for ventilation of the appliance are observed as shown in the
following drawing. If the minimum clearances are not observed, the accumulated air
cannot escape and the compressor is in continuous operation, which shortens the life of
the appliance.
Appliance dimensions in mm and degrees
a
b
b2
c
d
e
f
g
h
470
495
923
1440
50
100
50
135°
792
Ø Failure to observe the minimum distances increases power
consumption.
Ø If the accumulated heat cannot dissipate around the appliance,
the function of the appliance will be impaired.
Ø To achieve the specified energy class, comply with the above
mentioned clearances.
Ø Do not install refrigerator/freezer combinations with only one
temperature regulator in refrigerated rooms below 16 °C
Levelling
If the surface is slightly uneven, level the appliance with the front feet.
Page 9
KGC231-60-E-050CB
Version 10/2023
Setting up & Connecting device
