Swapping door hinges
STEP-BY-STEP INSTRUCTIONS
FIGURE
1. Remove the hinge cover and the upper hinge from the
upper right side of the unit.
2. Remove the screw hole cover from the upper left side of
the unit.
3. Lift the refrigerator door out of the middle hinge. Slide the
hinge plug from the upper left side to the upper right side
of the door.
4. Remove the centre hinge from the right-hand side.
Remove the covers of the screw holes on the left side.
5. Lift the freezer door out of the bottom hinge. Slide the
hinge plug from the upper left to the upper right side of
the door.
6. Remove thedoor stop from the lower right side of the
door and attach it to the lower left side of the door.
7. Remove the lower hinge from the lower right side of the
unit. Remove both adjustable feet. Remove the lower
hinge pin from the hinge, turn the hinge over and replace
the hinge pin on the other side. Screw the lower hinge
onto the bottom left side of the unit. Screw on both
adjustable feet.
8.
9. Carefully fit the appliance door onto the pin of the middle
hinge and close the door. Place the hinge on the appliance
door with the pin facing downwards and screw it tight with
3 screws. Fit the screw hole cover on the upper right side
of the unit.
Setting up the appliance
Place the appliance
• in accordance with the prescribed minimum clearances.
• Set up the appliance in a dry, well-ventilated room whose ambient temperature
corresponds to the climate class for which the appliance is designed.
ATTENTION
APPLIANCE DAMAGE!
Leave the appliance to stand for 12 hours after transport to allow the refrigerant to
collect in the compressor. Failure to observe this may damage the compressor and cause
the appliance to fail. This would void all warranty claims.
Page 8
KGC231-60-E-050CB
Version 10/2023
Setting up & Connecting device
Attach freezer door and attach the centre hinge on the left
side of the unit. Fit the cover to the screws holes
