© signotec GmbH 2000-2024
signoSign/2 Documentation
Rev. B
Page 13 of 73
The Include only the end certificate in the X.509 certificate chain information. setting
has the following effect: from the complete certificate chain for the signature, only the
end certificate used for signing will be inserted as information in the document. This
option is disabled by default, so the entire certificate chain is included.
The Exchange certificate of the signature device option for the biometrics certificate
allows you to specify that the certificate stored in the certificate file is to be loaded onto
the signature pad. This is carried out on a general basis. With the Only if no certificate is
stored in the signature device setting, you can ensure that the certificate will only be
exchanged if there is none in the signature pad. Otherwise, the stored certificate is
retained. Both options are enabled by default.
To be able to use the certificates in the signature pad, a Sigma (from
firmware 1.16), an Omega (from firmware 1.25), Sigma Lite, Alpha, Gamma,
Delta or Zeta is required.
Selecting an existing certificate
Use the button to select a certificate.
A window then opens where you can access an ‘Open file...’ dialog by clicking the same
button; here you can select the certificate (.p12 or .pfx for the signature certificate or .cer,
.cert or .crt for the biometric certificate). These are the file formats we recommend for the
certificates to be used. After making the selecting, the certificate is displayed under File
and the corresponding Password for the certificate must be entered. You can use the
option Save password to specify whether the password will need to be entered for each
document before the signing process. The following information about the selected
certificate is also displayed once the correct password has been entered: Owner, Serial
number, Hash value, Duration of validity and Key length.
Creating a new certificate
Instead of selecting an existing certificate, you can create a new, self-signed certificate by
clicking on the corresponding button.
A window will then open where you can enter the data relevant to the certificate. The
mandatory fields marked in red Name, Company, Password and Repeat password must
be filled out. All other fields such as E-mail address, Organisational unit, City, Federal
State and Country are optional and you can thus leave them blank. You can use the
option Save password to specify whether the password will need to be entered for each
document before the signing process. You can use the setting Duration of validity to
define how long the certificate should remain valid. You can either choose a period
between 1 and 10 Years or enter a year under Valid until end of, which can correspond to
more than 10 years of validity and will expire on 31.12.XXXX. With a Key length of up to
4096 bits, we offer the highest degree of security and the latest security technology.
Click OK to confirm your entries and display a ‘Save as...’ dialog. Here you can save the
created signature or biometrics certificate in a location of your choosing. The biometrics
certificate is saved split up into a public and a private key. The selected path is then shown
as a certificate file and this certificate is then used for all future signing processes.
