Notes

– The vacuum cleaner is set to MID suction power when switched on.

Dust container (B)

If you find out that the suction performance of the vacuum cleaner is reduced, make sure

that the dust container is not full and if necessary, empty it. Put the container above

a dust bit and press button B6; thus you will lift off bottom and throw the dust in common

municipal waste (Fig. 7). Snap the bottom shut to secure it in the opposite direction. For

sanitary reasons we recommend emptying the container outside housing premises.

After about 5 emptying of the container we recommend complete cleaning of the filtration

system to remove the settled dust. Press container lock button B5 and then remove

container B from the vacuum cleaner (Fig. 7). The separátor B3, HEPA-filter B1 and foam

micro-filter B2

pull it out of the container. Tap the dust out of the HEPA filter over a dustbin

or to clean the filter through a blowing (we recommend the filter cleaning outside of living

area for hygiene reasons). If the protection micro filter is very dirty, you can also rinse the

pleated side of the HEPA filter under lukewarm slow-running tap. Hold the filter in such a

way that the pleated side points upwards and the water flows parallel to the pleats. Hold

the filter at an angle so that the water washes away the dirt inside the pleats. Turn the filter 180°

and let the water flow along the pleats in the opposite direction. Continue this process until the

filter is clean. After drying, insert the cartridge back to the container in the opposite way.

If the separator B3 is blocked by foreign objects, pull out the rubber plug B7 insider the

separator B3, then take out the foreign objects and clean the air channel (Fig. 7).

Clean all other parts (i.e. container, separator, foam micro-filter) in running lukewarm

water, e.g. using a cloth or a soft brush and let it dry completely. Re-assemble individual

parts in the opposite direction.

D – Dust container

If you find out that the suction performance of the vacuum cleaner is reduced, make sure

that the dust container is not full and if necessary, empty it. Press container lock button E2

and then remove container D from the extension adapter E (Fig. 8). The suction chamber

lid D1, filter D2 and separator D3

pull it out of the container. Clean all parts in running

lukewarm water, e.g. using a cloth or a soft brush and let it dry completely. Re-assemble

individual parts in the opposite direction.

Storage

Store the appliance thoroughly clean on a dry, dustless place out of reach of children and

persons sui juris. Do not put the assembled rod vacuum cleaner on an uneven surface!

The cleaner must be placed on a flat surface where there is no danger of knocking over.

Insert one of the accessories (small turbobrush G1, crevice nozzle G2, flexible joint G3)

into charging stand H.

V. MAINTENANCE

Before any maintenance, disconnect the charging adapter from the appliance. Clean the

vacuum cleaner surface and the charging adapter with a soft damp cloth; do not use abrasive

and aggressive cleaning agents! Never dry plastic moldings over a heat source (e.g. heater,

electric/gas stove). Check and clean the vacuum channel of floor nozzle brush and the main

stick body (above the reservoir) occasionally. Remove the blockage and take out any waste.

38 / 79
