Floor nozzle F, rotary small turbobrush G1

Wipe the floor nozzle with a damp cloth. After every vacuuming, check if any dirt is trapped

in the rotating brush. If the brush is unclean, please remove it from the floor nozzle

according to Fig. 9, 10. Now you may easily clean the brush (rinse it in running water).

After wash the roller brush, please dry the shaft at end of brush (milky plastic location)

with damp cloth to avoid rusting. Warning: Do not water the floor nozzle in running water

directly, it will damage motor and PCB. After the maintenance, apply a reverse procedure

to install the brush in the nozzle and secure it. Wipe the UV light cover with a damp cloth.

The UV lamp has a long service life. However, if it stops working or gets damaged, please

contact an authorized service centre for replacement.

Release the two arrest latches F3 on the bottom side of the nozzle in the direction of the arrow

and remove the cover (Fig. 11).

Release the holder F4, then take out the hose from groove to clean it. Clean the space with a

suitable tool (e.g. tweezers). After cleaning, reassemble it.

Accessories (G2, G3)

After any vacuuming it is recommended to check visually the brushes or collectors for

possible impurities. If there are some impurities, remove them.

Other parts (C, E)

extension adapter/suction tube C and extension adapter E with a wet cloth. Allow all the

parts to dry out properly before re-use.

Mop extension cleaning (G4, G5)

Remove the extension from the vacuum cleaner after each use. Pour excess water from

the reservoir. Rinse the mop extension under running water. The mop textile can be washed

in a washing machine at 60 °C and dried in a tumble dryer. Allow everything to dry thoroughly

before reuse! Always store the water tank with the cap removed from the filling hole.

CAUTION

–

The maximum suction effect will be reached with a clean filter and an empty container.

– Do not use any aggressive washing or cleaning agents or hot water to clean the filter.

– The filter is not intended for washing in a dishwasher.

–

Cleaning the filter will not restore its original colour, but it will restore its filtration properties.

– In order to maintain the filtering parameters of the HEPA filter, we recommend that you

use a dry method of cleaning.

–

If you clean the HEPA filter with water, its filtration properties will deteriorate. The filter

cannot be washed more than three times. After that, a new filter needs to be purchased.

– Neglecting filter cleaning may lead to breakdown of the vacuum cleaner!

– Make sure that the contact surfaces and sealing elements are functional.

– We recommend replacing the filter once a year or when it cannot be cleaned properly or

if it is damaged. You can buy a replacement st filter in the elektro shop chain.

Dust container

Rinse the dust container in running water and let it thoroughly dry.

CAUTION

The dust containers (B, D) is not resistant to cleaning in a dishwasher.

39 / 79
