CAUTION

– The floor nozzle with the rotation brush F is not intended for vacuuming impurities

from carpets with high pile.

– When you are using the floor nozzle F or small turbobrush G1 and the rotary brush will

get blocked, (e.g. due to sucking in large foreign objects, due to winding carpet piles,

threads or hair on them etc.) turn off the vacuum cleaner by switch A1 or C1. Then

remove the cause of blocking or clean the rotation brush if necessary (see par.

V. MAINTENANCE).

USING THE MOPING ATTACHMENT

Attach the G5 mop to the lower part of the moping attachment correctly. On the underside

there are surfaces with Velcro, which are designed for attaching the cloth. Soak and wring

the mop before use. Open the rubber stopper and fill the mop attachment G4 with water

(max 85 ml). If you want to add a liquid floor cleaner to the water in the mop attachment,

make sure that you use a lowfoaming or non-foaming liquid floor cleaner that can be

diluted in water.

Place the mop attachment in place in the floor nozzle F. Only move

forwards and backwards. As it moves, the mop is then kept wet by the water from the mop

attachment. The water supply can keep the mop moist for about 10-15 minutes. If you notice

the floor being wiped dry, it is necessary to add water to the mop attachment.

Notes

– Do not use the mop attachment on carpets.

– To prevent damage, never put wax, ethereal oils or similar substances in the mop

attachment. Do not use liquid that are not transparent or even milky floor maintenance

products or liquid floor cleaners that are not water-dilutable in the water tank.

– When mopping, check the vacuum cleaner and add water to the moping attachment, if

necessary, or rinse the mop.

– If your floor has not been treated to make it water-resistant, check with the manufacturer

if you can use water to clean it. Do not use the mop attachment on hard floors of which

the water-resistant top coat is damaged.

–

The mop attachment can be used while vacuum cleaning is on or off. If you are

mopping and vacuuming at the same time, first move the vacuum cleaner forwards on

the surface you are cleaning and then return using the same path you have already

vacuumed and cleaned. This will ensure the proper sequence of the cleaning process

- vacuum cleaning to get rid of any dirt first, followed by floor mopping.

– As this appliance uses water to clean, the floor may remain wet and slippery for a while.

– Remove and clean the moping attachment after use. Do not leave it installed on the

vacuum cleaner while charging battery.

OPERATION (Fig. 5):

1) Vacuum cleaner switching on/off

– The vacuum cleaner may be switched on/off by A1 switch, or by C1 switch if you use

the extension piece C.

2) Suction power setting

– The suction power is adjustable by A5 button or by C2 switch if you use the extension

piece C. Three suction power levels are available (high-MAX, medium-MID and

low-ECO = economic / silent mode).

37 / 79
