5.2 Installing and charging the battery

1

Rotate the battery house cover knob

to “Unlock” position; Pull battery

house cover out.

2

Insert battery into battery house.

3

Close battery house cover and turn

the knob to “Lock” position

4

Take battery out from battery housing

and charge battery

The battery is partially charged when delivered. It is recommended to charge the

batteries to 100% before the rst use.

It is recommended to charge the batteries at 100% before each use.

The charger must not be used for anything else than it was designed for. Do not

charge the battery in a potentially explosive area. The charger must only be used indoors.

The charger regulates the charge automatically, once the battery is fully charged, it will

maintain it at a 100% (oating charge).

The charge time is 3 to 4 hours.

The battery will discharge itself after long storage periods. Always charge the bat-

tery if the device was stored for more than 15 days. When the battery is new or has been

stored for more than 3 months, charge it and discharge it at least twice in a row to resume

the nominal/rated charge capacity.

Battery charge:

1. Take battery out from battery housing

2. Connect the battery to the charger using the input located at the top of the battery.

3. Connect the charger to the main power source.

4. The state of charge is displayed via a red LED on the main power source charger.

5. Once the charge is nished, the oating charge becomes active: the red LED switches

OFF and a green LED switches ON.

6. Disconnect the charger from the outlet (do not keep the charger plugged to the main

power source if it’s not in use).
