BrightEye 3

Pwr (Power)

Illuminates green when power is applied to the converter and the internal voltage

regulator is functioning correctly.

ADJUSTING PARAMETERS FROM THE FRONT PANEL

Use the Mode, Right Arrow, and Left Arrow buttons to select and adjust

parameters from the front panel.

Pressing the Mode button activates the front panel for editing and tabs between

each section of editable parameters.

Pressing the Right Arrow or Left Arrow advances the selection within a given

section of parameters, or increases (Right Arrow) or decreases (Left Arrow) the

value of a selected parameter.

The LED of an edited parameter will blink for 15 seconds, after which time its value is

stored in memory. If power is interrupted before this 15 second timeout period has

elapsed, the edited state will not be not saved.

The controls and their indicators are described below:

Mode

This control selects the conversion mode with the following choices:

A –> D – Convert analog to digital audio

D –> A – Convert digital to analog audio

BiDir – Convert two channels of analog to digital and simultaneously

convert two channels of digital to analog

SRC – Convert the sample rate of the AES In and output the reclocked

audio on AES Out, with simultaneous analog monitoring

Analog Ref Level

This control selects analog reference levels for input and output, with the

following choices:

-10 dB – Accept -10 dB inputs, and provide -10 dB outputs

+4 dB – Accept +4 dB inputs, and provide +4 dB outputs

BrightEye-11

NOTE:
