BrightEye 10 Optical/SDI to Analog/SDI Converter

BrightEye-8

ADJUSTING PARAMETERS FROM THE FRONT PANEL

Use the Mode, Right Arrow, and Left Arrow buttons to select and adjust

parameters from the front panel.

Pressing the Mode button activates the front panel for editing and tabs between

each section of editable parameters.

Pressing the Right Arrow or Left Arrow advances the selection within a given

section of parameters, or increases (Right Arrow) or decreases (Left Arrow) the

value of a selected parameter.

The LED of an edited parameter will blink for 15 seconds, after which time its value is

stored in memory. If power is interrupted before this 15 second timeout period has

elapsed, the edited state will not be not saved.

The controls and their indicators are described below:

Input

This control selects the video input format with the following choices:

Optical – Fiber optic video

SDI – Serial digital component video

Output

This control selects the video output with the following choices:

Beta – Component Video in Beta format

SMPTE – Component Video in SMPTE format

RGB – Component Video in RGB format

Cpst – NTSC or PAL Analog Composite Video with simultaneous Y/C (use a

standard S-Video Y/C adapter on the two inputs)

The selected output will be indicated by a green indicator.
