22 Channel setting in the ETS
Remote Control Remo KNX RF • Version: 14.09.2021 • Technical changes and errors excepted.
Input type – Dimming:
If the channel should be used to dim a light (dimming actuator), select ‘Input’ type and the
‘Dimming’ function and determine if after completing a dimming command, feedback
should be sent to the remote control.
Choose whether buttons should be used for dimming. If you deactivate buttons, you
must activate the slide bar below to enable dimming!
Then set the time interval between switching and dimming for the buttons; if desired, set
the repeat interval and the percentage value for long button press.
Activate the function if the lighting is to be dimmed via the slide bar. If the slide bar AND
buttons are activated, the small area next to the bar can be used to switch between the op-
erating functions. If none of the operating functions are active, the channel is not functional.
Input type – RGB/RGBW:
If the channel is to be used to control a light with adjustable colours (RGB or RGBW), select
the ‘Input’ type and the ‘RGB/RGBW’ function and set whether after completing an RGB
command, feedback for the movement should be sent to the remote control.
Choose whether buttons should be used for adjustment. If you deactivate the buttons,
you must activate at least one of the slide bars below to enable adjustments!
Enter the label for the ‘switched-on’ and ‘switched-off’ states. The label can also be changed
directly on the device.
Type Input
Function Dimmer
Use feedback No • Yes
Use buttons No • Yes
Time between switching and dimming
(in 0.1 s)
1...50; 5
Repetition of the dimming command No • Yes
Repetition of the dimming command
on long button actuation
(if dimmer command is repeated)
every 0.1 s... • every 2 s; every 0.5 s
Dimming by
(if dimmer command is repeated)
1.50% • 3% • 6% • 12.50% • 25% • 50%
Use slide bar No • Yes
Type Input
Function RGB/RGBW
Use RGB feedback No • Yes
Use buttons No • Yes
Channel label for display on (right side) [Free text max. 5 characters] 1
Channel label for display off (left side) [Free text max. 5 characters] 0
