23 Channel setting in the ETS
Remote Control Remo KNX RF • Version: 14.09.2021 • Technical changes and errors excepted.
Set the switch-off send behaviour for the buttons using the 3-byte object (RGB together)
and the three or four 1-byte objects (R, G, B and W separately). Choose whether on/off feed-
back should be received via the bus. Set the time interval for the buttons between switching
(tapping) and sending the RGB value (when holding the button longer).
For every colour that has no slide bar assigned to it (see next section on settings), you can
select any other channel to assign this colour to. Thus, it is possible to set the colours of an
RGB light to different channels of the remote control, and to display the slider bars for red,
green, blue and white one under another.
Activate the functions if individual colours must be adjusted using a slide bar. If the slide
bar or multiple slide bars AND buttons are activated, the small area next to the bar can be
used to switch between the operating functions. If none of the operating functions are ac-
tive, the channel is not functional.
The new RGB(W) value set via the slide bar can be sent to the KNX bus by pressing and
holding the button. The corresponding 1-byte objects are sent as soon as you release the
slide bar.
Input type – Colour temperature:
If the channel is to be used to control a light with adjustable colour temperature (warm
white/cold white), select the ‘Input’ type and the ‘Colour temperature’ function.
The 3-byte object is to send the value 0
when switching off
No • Yes
The three/four/rgbw 1-byte objects are to
send the value 0 when switching off
No • Yes
Use on/off feedback No • Yes
Channel label in feedback on
(only if there is feedback)
[Free text max. 5 characters] 1
Channel label in feedback off
(only if there is feedback)
[Free text max. 5 characters] 0
Time between switching and sending the
RGB value in increments of 0.1 sec
1...50; 5
Red/green/white/blue proportion without • Channel 1...32
Use red slide bar No • Yes
Use green slide bar No • Yes
Use blue slide bar No • Yes
Use white slide bar No • Yes
Type Input
Function Colour temperature
