48 Automatic settings
Control System KNX WS1000 Style • Version: 28.05.2018 • Technical changes and errors excepted.
• Exhaust air levels / exhaust air intensity (only for roof ventilators WL400/800 an
ventilators at RF-VM)
• Night-time re-cooling (together with indoor temperature for night-time re-
cooling)
• Timed ventilation (and levels for timed ventilation)
• Outdoor temperature (only for air supply devices)
• Recirculating air for heat recovery (only roof ventilators WL400/WL800)
• Recirculating air for condensation reduction (only for roof ventilators WL400/
WL800)
• Temperature for heating (only for fresh air/heating-combos on RF-VM)
• Enable/Disable automatic reset
As soon as a connected air conditioner is activated, ventilation is disabled, including
manually activated fans. The fans can be manually operated again immediately. The
delay time for the ventilation block can be adjusted.
System > Automatic Settings > General Settings > Ventilation Block
3.3. Adjust ventilation block
Ventilation according to temperature, humidity and CO
2
is checked every second.
For exhaust air units (radio roof ventilation units, units at RF-VM), the more one of the
values is above the setpoint value, the higher the air flow rate is increased. However,
the air flow rate is only reduced again when the new required ventilation level is 20%
lower than the current one (delay/hysteresis). The set minimum and maximum venti-
lation intensity is maintained.
In supply air units (WL-Z unit at MF output or radio relay), the ventilation flap is opened
as soon as one of the values is above the adjusted setpoint. However, it is only closed
again when the new required ventilation level is 20% lower than the current one (delay/
hysteresis).
The automatic ventilation functions can be accessed by pressing the buttons:
Now you can select individual ventilators and adjust their settings. For each ventilator
the following settings can be changed:
Press the button to select the indoor sensor the control system will use for this venti-
lator (Pre-setting: Internal sensor at WS1, first sensor in the list at WS1000). As long as
“No Sensor” is selected, the indoor temperature and air humidity will not be taken
into account by the control system for this ventilator.
Confirm your setting with the OK button.
Automatic
Settings
VentilationSystem
Sensor Selection
For all ventilation units.
