6 Description
Sensor KNX VOC/TH-UP Touch as of software 0.1.0 • Version: 30.11.2021 • Technical changes and errors excepted.
• 2 actuating variable comparators for output of minimum, maximum or
average values. Each with 5 inputs (for values received via communication
objects)
Configuration is made using the KNX software as of ETS 5. The product file can be
downloaded from the ETS online catalogue and the Elsner Elektronik website on
www.elsner-elektronik.de in the “Service” menu. There you will also find the
product manual.
1.1. Scope of delivery
• Housing with display
• Base plate
You will need in addition (not supplied):
• Device socket according to DIN 49073
• Frame (for element 55 x 55 mm), suitable for the switching programme used in
the building
1.2. Technical specifications
Housing Plastic material
Colours • similar to RAL 9005 jet black
• similar to RAL 9010 pure white
Mounting on device socket according to DIN 49073
Degree of protection IP 20
Dimensions Housing approx. 55 x 55 (W x H, mm), mounting depth
approx. 8 mm, base plate approx. 71 x 71 (W x H, mm)
Total weight approx. 68 g
Ambient temperature Operation 0…+50°C, storage -10…+60°C
Ambient air humidity 10...95% RH, avoid bedewing
Operating voltage KNX bus voltage
Bus current max. 20 mA
Data output KNX +/- bus terminal plug
Group addresses max. 254
Allocations max. 254
Communication objects 224
VOC measurement range 400...2000 ppm
VOC resolution 1 ppm
Temperature measurement
range
0…+50°C
Temperature resolution 0.1°C
Humidity measurement
range
0% RH …95% RH
Humidity resolution 0.1%
Humidity drift ± 0.5% RH per year in normal air
