7 Installation and commissioning
Sensor KNX VOC/TH-UP Touch as of software 0.1.0 • Version: 30.11.2021 • Technical changes and errors excepted.
The product conforms with the provisions of EU guidelines.
1.2.1. Accuracy of the measurement
Measurement variations from permanent sources of interference (see chapter
Installation position) can be corrected in the ETS in order to ensure the specified
accuracy of the sensor (offset).
To ensure a correct VOC measurement, the device must be installed in a windproof
socket.
When measuring temperature, the self-heating of the device is considered by the
electronics. The heating is compensated by the software.
1.2.2. Measuring ranges of different gases (CO2 equivalents)
Corresponding VOC concentrations for specific representatives
* corresponding concentration range based on lab measurements at gas mixing system with synthetic air at 50% r.h. and RT
2. Installation and commissioning
Installation, testing, operational start-up and troubleshooting should
only be performed by an authorised electrician.
CAUTION!
Live voltage!
There are unprotected live components inside the device.
• Inspect the device for damage before installation. Only put undamaged
devices into operation.
Compound Formula Range*
(ppm)
Potential sources of pollutants
indoors
Carbon monoxide CO 0-10 Car exhaust, fuel-based heating, cook-
ing appliances, smoking
Methane CH
4
0-200 Natural gas
Propane C
3
H
8
0-20 Fuel-based heating, cooking appli-
ances, cleaners
Ethyl alcohol C
2
H
6
O 0-3 Cosmetics, cleaners, disinfectants,
detergents, paints, coatings, breath
Acetaldehyde C
2
H
4
O 0-20 Adhesives, coatings, plastics,
lubricants, ripening of fruits
Methylethylketone C
4
H
8
O 0-20 Adhesives, coatings, plastics,
lubricants
Toluene C
7
H
8
0-5 Paints, coatings, cleaners, detergents,
smoking, polyurethane lacquers
