5 Description
Sensor KNX VOC/TH-UP Touch as of software 0.1.0 • Version: 30.11.2021 • Technical changes and errors excepted.
1. Description
The Sensor KNX VOC/TH-UP Touch measures volatile organic compounds in the
room air, temperature and humidity and calculates the dew point. The sensor can
receive external measured values via the bus and process them with the own data to
overall values (mixed values, e. g. room average). The KNX VOC/TH-UP Touch offers
two push buttons that may be used for changing the ambient temperature (target
value), for switching between operating modes or as free programmable bus push
buttons.
The KNX VOC/TH-UP Touch provides switching outputs with adjustable threshold
values. The switching outputs and further communication objects can be linked by
AND and OR logic gates. Additionally, an integrated actuating variable comparator can
compare and output values that are received via communication objects.
Integrated PI controllers allows for control of a ventilation (depending on VOC
concentration and air humidity) and a heating/cooling system (depending on
temperature). The KNX VOC/TH-UP Touch can emit a warning to the bus as soon as
the area of optimum comfort (according to DIN 1946) is left.
The integrated display shows the own values and data received from the bus (e.g. date,
time). The device is completed with a frame of the switching series installed in the
building and thus merges with the interior.
Functions:
• Measurement of VOC (volatile organic compounds) in the air. In this process,
an air quality value in CO
2
equivalents is calculated via an algorithm from the
sum signal of all compounds included in the mixed gas.
• Measurement of temperature and air humidity (absolute and relative),
calculation of the dew point
• Mixed values from own measured values and external values (proportions
can be set in percentage)
• Display 1-3 rows (own values or values received from the bus) or display of
temperature control (see Mode display and manual temperature controller)
• 2 push buttons. Configuration as bus push button or for changing ambient
temperature and switching between operating modes (see Change ambient
temperature with the buttons)
• PI controller for heating (one or two step) and cooling (one or two step)
depending on temperature. Control according to separate target values or
basic target temperature
• PI controller for ventilation depending on humidity and VOC concentration:
dehumidification/humidification (one step) or dehumidification (one or two
step)
• Threshold values can be adjusted per parameter or via communication
objects: 3 × temperature, 2 × humidity, 4 × VOC
• 4 AND and 4 OR logic gates with each 4 inputs. Every switching incident as
well as 16 logic inputs in the form of communication objects, may be used as
inputs for the logic gates. The output of each gate may optionally be configured
as 1 bit or 2 x 8 bits
