37 Parameter setting
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
A set setpoint value will be retained until a new value or a change is transferred. The
current value is saved, so that it is retained in the event of a power supply failure and
will be available once the power supply is restored.
Setpoint value setting using parameter:
Set the threshold values and hysteresis directly.
Setpoint value setting using communication object:
In "Humidification and dehumidification" control mode, a dead zone is specified so that
a direct changeover switching between humidification and dehumidification can be
avoided.
Humidification starts, when the relative air humidity is lower or equal to the setpoint
value - dead zone value.
Dehumidification and/or humidification
Depending on the control mode, settings sections for humidification and dehumidifi-
cation appear (level 1/2).
For dual-level dehumidification, the setpoint value difference between the two levels
must be defined, i.e. the setpoint value which, when exceeded, triggers the switch to
the 2nd level.
Setpoint value setting using Parameter • Communication objects
Setpoint value in 0.1% RH
(valid until 1st communication)
0 … 100; 70
Setpoint value setting using Parameter • Communication objects
The value communicated last shall be
maintained
• never
• after power supply restoration
• after power supply restoration and
programming
Start setpoint in %
valid until first communication
(not upon saving the setpoint value after
programming)
0 … 100; 50
0…100; 40
Object value limit (min.) in % 0…100; 60
Object value limit (max.) in % Absolut value • Increase / Decrease
1,00% • 2,00% • 5,00% • 10,00%
Dead zone between humidification and
dehumidification in %
(only if both humidification and dehumidifi-
cation are used)
0…50; 15
Target value difference between level 1
and 2 in %
(for level 2 only)
0...50; 15
