11 Transfer protocol
Sensor KNX T-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
15 Temp. thresholdV 1: Switching
output block
Input -WC- [1.2]
DPT_Bool
1 Bit
16 Temp. thresholdV 2: Absolute
value
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
17 Temp. thresholdV 2: (1:+ | 0:-) Input -WC- [1.2]
DPT_Bool
1 Bit
18 Temp. thresholdV 2: Switching
delay from 0 to 1
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
19 Temp. thresholdV 2: Switching
delay from 1 to 0
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
20 Temp. thresholdV 2: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
21 Temp. thresholdV 2: Switching
output block
Input -WC- [1.2]
DPT_Bool
1 Bit
22 Temp. thresholdV 3: Absolute
value
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
23 Temp. thresholdV 3: (1:+ | 0:-) Input -WC- [1.2]
DPT_Bool
1 Bit
24 Temp. thresholdV 3: Switching
delay from 0 to 1
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
25 Temp. thresholdV 3: Switching
delay from 1 to 0
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
26 Temp. thresholdV 3: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
27 Temp. thresholdV 3: Switching
output block
Input -WC- [1.2]
DPT_Bool
1 Bit
29 Temp.control: HVAC mode
(priority 1)
Input -WC- [20.102]
DPT_HVACMode
1 Byte
30 Temp.control: HVAC mode
(priority 2)
Input /
Output
RWCT [20.102]
DPT_HVACMode
1 Byte
31 Temp.control: Mode frost/heat
protection activt.
Input /
Output
RWCT [1.1]
DPT_Switch
1 Bit
32 Temp.control: Block (On when
value = 1)
Input -WC- [1.1]
DPT_Switch
1 Bit
33 Temp.control: Current setpoint Output R-CT [9.1]
DPT_Value_Temp
2 Bytes
34 Temp.control: Switch. (Heating
= 0 | Cooling = 1)
Input -WC- [1.1]
DPT_Switch
1 Bit
35 Temp.control: Setpoint Comfort
heating
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
36 Temp.control: Setpoint Comfort
heat.(1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
37 Temp.control: Setpoint Comfort
cooling
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
No Name Function Flags Data Point Type Size
