Je bekijkt pagina 14 van 46
12 Transfer protocol
Sensor KNX T-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
38 Temp.control: Setpoint Comfort
cool.(1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
39 Temp.control: Basic 16-bit set-
point shift
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
40 Temp.control: Setpoint Standby
heating
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
41 Temp.control: Setpoint Standby
heat.(1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
42 Temp.control: Setpoint Standby
cooling
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
43 Temp.control: Setpoint Standby
cool. (1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
44 Temp.control: Setpoint Eco hea-
ting
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
45 Temp.control: Setpoint Eco hea-
ting (1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
46 Temp.control: Setpoint Eco coo-
ling
Input /
Output
RWCT [9.1] DPT_-
Value_Temp
2 Bytes
47 Temp.control: Setpoint Eco coo-
ling (1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
48 Temp.control: Control variable
heating (level 1)
Output R-CT [5.1]
DPT_Scaling
1 Byte
49 Temp.control: Control variable
heating (level 2)
Output R-CT [5.1]
DPT_Scaling
1 Byte
50 Temp.control: Control variable
cooling (level 1)
Output R-CT [5.1]
DPT_Scaling
1 Byte
51 Temp.control: Control variable
cooling (level 2)
Output R-CT [5.1]
DPT_Scaling
1 Byte
52 Temp.control: Status Heat. level
1 (1=ON|0=OFF)
Output R-CT [1.1]
DPT_Switch
1 Bit
53 Temp.control: Status Heat. level
2 (1=ON|0=OFF)
Output R-CT [1.1]
DPT_Switch
1 Bit
54 Temp.control: Status Cool. level
1 (1=ON|0=OFF)
Output R-CT [1.1]
DPT_Switch
1 Bit
55 Temp.control: Status Cool. level
2 (1=ON|0=OFF)
Output R-CT [1.1]
DPT_Switch
1 Bit
56 Temp.control: Comfort exten-
sion status
Input /
Output
RWCT [1.1]
DPT_Switch
1 Bit
57 Temp.control: Comfort Exten-
sion time
Input RWCT [7.5]
DPT_TimePeriodSec
2 Bytes
58 Temperature control: Variable
for 4/6-way valve
Output R-CT [5.1]
DPT_Scaling
1 Byte
131 CO2 control: Act. variable venti-
lation (1.stage)
Output R-CT [5.1]
DPT_Scaling
1 Byte
No Name Function Flags Data Point Type Size
