Je bekijkt pagina 12 van 46
10 Transfer protocol
Sensor KNX T-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
5. Transfer protocol
Units:
Temperatures in degrees Celsius
Air humidity in %
Absolute air humidity in g/kg and/or g/m
3
Variables in %
5.1. List of all communications objects
Abbreviation flags:
C Communication
R Read
WWrite
T Transfer
UUpdate
No Name Function Flags Data Point Type Size
0 Software version readable R-CT [217.1]
DPT_Version
2 Bytes
1 Temperature sensor malfunc-
tion
Output R-CT [1.1]
DPT_Switch
1 Bit
3 External measured value for
temperature
Input -WC- [9.1]
DPT_Value_Temp
2 Bytes
4 Internal measured value for
temperature
Output R-CT [9.1]
DPT_Value_Temp
2 Bytes
5 Total measured value for tempe-
rature
Output R-CT [9.1]
DPT_Value_Temp
2 Bytes
6 Request min./max. temperature
measured value
Input -WC- [1.17]
DPT_Trigger
1 Bit
7 Minimum measured value for
temperature
Output R-CT [9.1]
DPT_Value_Temp
2 Bytes
8 Maximum measured value for
temperature
Output R-CT [9.1]
DPT_Value_Temp
2 Bytes
9 Reset min./max. measured
value for temperature
Input -WC- [1.17]
DPT_Trigger
1 Bit
10 Temp. thresholdV 1: Absolute
value
Input /
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
11 Temp. thresholdV 1: (1:+ | 0:-) Input -WC- [1.2]
DPT_Bool
1 Bit
12 Temp. thresholdV 1: Switching
delay from 0 to 1
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
13 Temp. thresholdV 1: Switching
delay from 1 to 0
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
14 Temp. thresholdV 1: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
