43 Parameter setting
Sensor KNX AQS/TH-UP Touch • Version: 02.08.2022 • Technical changes and errors excepted.
6.11. Comfort field
The Sensor KNX AQS/TH-UP Touch can send a message to the bus if the limits of
the comfort field are exceeded. In this way, it is for example possible to monitor com-
pliance with DIN 1946 (standard values) or even to define your own comfort field.
Define the comfort field by specifying the minimum and maximum values for temper-
ature and humidity. The specified standard values comply with DIN 1946
Temperature hysteresis: 1°C
Relative humidity hysteresis: 2% RH
Absolute humidity hysteresis: 2 g/kg
6.12. CO
2
parameter settings
Select (see General settings, Seite 21), whether a malfunction object is to be sent if
the sensor is faulty.
The CO
2
sensor uses the last 7 minimum CO
2
values for automatic sensor calibration.
These 7 minimum values must be at least 18 hours apart and within the range of 400
to 450 ppm (fresh air).
Use Offsets to adjust the readings to be sent.
Use comfort field No • Yes
Sending pattern • never
• periodically
• on change
• on change and periodically
Send cycle (if sent periodically) 5 s • 10 s • 30 s… • 2 h
Maximum temperature in °C
(Standard 26°C)
25 ... 40; 26
Minimum temperature in °C
(Standard 20°C)
10 ... 21; 20
Maximum relative humidity in %
(Standard 65%)
52 ... 90; 65
Minimum relative humidity in %
(Standard 30%)
10 ... 43; 30
Maximum absolute humidity in 0.1 g/kg
(Standard 115 g/kg)
50 ... 200; 115
Use malfunction object No • Yes
Use automatic sensor calibration No • Yes
Offset in ppm -100…100; 0
