44 Parameter setting
Sensor KNX AQS/TH-UP Touch • Version: 02.08.2022 • Technical changes and errors excepted.
The unit can calculate a mixed value from its own reading and an external value. Set
the mixed value calculation if desired. If an external portion is used, all of the following
settings (threshold values, etc.) are related to the overall reading.
The maximum reading can be saved and sent to the bus. Using the "Reset CO2 max-
imum value" objects, the value can be reset to the current reading. The value is not re-
tained after a reset.
6.13. CO2 threshold values
Activate the required CO2 threshold value. The menus for setting the threshold values
are displayed.
300 ppm ... 1000 ppm: fresh air
1000 ppm ... 2000 ppm: used air
1000 ppm = 0.1 %
6.13.1. Threshold value 1, 2, 3, 4
Threshold value
Set, in which cases threshold values and delay times received via object are to be
retained. The parameter is only taken into consideration if the setting via object is ac-
tivated below. Please note that the setting "After power supply restoration and pro-
gramming" should not be used for the initial start-up, as the factory settings are always
used until the first communication (setting via objects is ignored).
Set the threshold value directly in the application program using parameters, or define
them via the bus using a communication object.
Use external measured value No • Yes
Ext. Reading proportion of the total reading 5% • 10% • ... • 50% • ... • 100%
All of the following settings are referred to the total value.
Sending pattern for internal and total
measured value
• never
• periodically
• on change
• on change and periodically
At and above change of
(relative to the last measured value)
(if sent on change)
2% • 5% • ... • 50%
Send cycle (if sent periodically) 5 s • 10 s • ... • 2 h
Use maximum value No • Yes
Use threshold value 1/2/3/4 Yes • No
