42 Parameter setting
Sensor KNX AQS/TH-UP Touch • Version: 02.08.2022 • Technical changes and errors excepted.
The behaviour of the switching output on release is dependent on the value of the pa-
rameter "Switching output sends" (see "Switching output")
6.10. Absolute humidity
The absolute air humidity value is detected by the KNX AQS/TH-UP Touch and can
be output to the bus.
Use switching output block No • Yes
Analysis of the blocking object • At value 1: block | At value 0: release
• At value 0: block | At value 1: release
Blocking object value before first communi-
cation
0 • 1
Behaviour of the switching output
On block • Do not send message
• send 0
• send 1
On release
(with 2 seconds release delay)
[Dependent on the "Switching output
sends" setting]
Switching output sends on change • Do not send message
• Send switching output status
Switching output sends on change to 1 • Do not send message
• if switching output = 1 send 1
Switching output sends on change to 0 • Do not send message
• if switching output = 0 send 0
Switching output sends on change and
periodically
Send switching output status
Switching output sends on change to 1
and periodically
if switching output = 1 send 1
Switching output sends on change to 0
and periodically
if switching output = 0 send 0
Use absolute humidity No • Yes
Sending pattern • never
• periodically
• on change
• on change and periodically
At and above change of
(if sent on change)
0,1 g • 0,2 g • 0,5 g • 1,0 g • 2,0 g • 5,0 g
Send cycle
(if sent periodically)
5 s • 10 s • 30 s… • 2 h
