49 System settings via ETS
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
If the period can be switched, i.e. is controlled via the bus by an external timer, no other
parameters are available. In case of an adjustable period (period object is output)
you can now set the time:
2.10. Alarm
The Display Corlo Touch KNX may trigger a wake-up call with a sound alarm and
flashing display at a pre-set time. At the same time, the display shows the time and a
button to switch the alarm off.
The wake-up call function of the Corlo Touch KNX can be changed via an object, on
the display or in the ETS menu.
ETS: alarm clock
Object control
For the settings via objects, i.e. via the bus, objects 80-84 are available. The objects are
input and output simultaneously, and thus may both receive a status change or
transmit the status to the bus autonomously. This means that the alarm clock may also
be activated, switched or set to snooze from, for example, a different location in the
building.
Object no. 81 sends or receives the wake-up time. This allows the alarm clock to be set
from another display as well.
Object no. 82 "Alarm clock warning status" can be configured as a bit object and
transmit the value 1 or 0 (e.g. to switch the light). Alternatively, the object may be
configured as a byte object and send a value between 0 and 255, or a percentage value
(e.g. for dimming lights, approaching a shade position or recalling a scene).
The alarm clock objects may be activated in the ETS. The following parameters only
appear when the objects are used ("yes").
Access code
(8 digits from 0 to 9)
[free text]
An empty field means that no code query is
done
Name
Languages 1...6
[free text]
An individual text may be entered for each
language
Start
Hour 0...23
Minute 0...59
End
Hour 0...23
Minute 0...59
Use weekday
Monday ... Friday Yes • No
