50 System settings via ETS
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
Adaptation on the display
The settings on the display are modified via the menu
Settings > system > alarm clock
and can be secured with an access code (set up in the ETS).
System settings via touch display > Alarm, Page 68
Modification via ETS
Select "Transmit the following parameters: Yes" to render the modifications valid.
Previous settings are then overwritten - including modifications done on the display!
The alarm clock menu on the display can be secured with an access code that is
determined (or deleted) in the ETS.
Use object for alarm clock • No
• Yes
Object value for alarm activation
Object no. 80 "alarm clock activation"
0 • 1
Object value for alarm acknowledgement
Object no. 83 "alarm clock
acknowledgement"
0 • 1
Object value for alarm repeat
Object no. 84 "alarm clock
warning repetition"
0 • 1
Alarm action
Object no. 82 "alarm clock warning status"
• transmit nothing
• transmit bit object (value 1)
• transmit bit object (value 0)
• transmit byte object (value 0...255)
• transmit byte object (value 0...100%)
Value
only for alarm clock action byte object
0...255; 255 or
0...100; 100
Transfer the following parameters Yes • No
Access code
(8 digits from 0 to 9)
[free text]
An empty field means that no code query is
done
Alarm time hour 0...23
Alarm time minute 0...59
Alarm duration 5 s • ... • 30 min • ... • 2 h
• until acknowledgement
Alarm repetition cycle in minutes
(0 = no repetition)
0...30; 5
Use alarm tone Yes • No
Display lighting flashes on alarm Yes • No
