48 System settings via ETS
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
transmitting the period objects from the output. The others then copy the time switch
command (input).
Periods must be pre-set in the ETC menu "weekly timer: period". Periods configured as
outputs may also be modified on the display.
ETS: Weekly timer
First, activate the periods to be set in the ETS. Sub menus for the activated
periods will appear.
The settings on the display are modified via the menu.
Settings > system > timer
The menu may be secured with an access code (set up in the ETS).
System settings via touch display > Timer, Page 70
2.9.1. Periods 1 ... 16
Now select whether the period is an input or an output for the activated periods of the
weekly timer (see above). Define the transmission behaviour for outputs.
ETS: Weekly timer > periods 1...16
Select "Transmit the following parameters: Yes" to render the modifications valid.
Previous settings are then overwritten - including modifications done on the display!
The timer menu on the display can be secured with an access code that is determined
(or deleted) in the ETS.
Use periods 1 ... 16 Yes • No
Period • is adjustable
(period object is output)
(period may also be set on the display)
• can be switched (time period object is
input)
(external time control)
Period output transmits
only if adjustable/output
• not
• on change
• on change to 1
• on change to 0
• on change and periodically
• on change to 1 and periodically
• on change to 0 and periodically
cycle
only if output transmits periodically
5 s • ... • 1 min • ... • 2 h
Transfer the following parameters Yes • No
