47 System settings via ETS
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
and can be secured with an access code (set up in the ETS).
System settings via touch display > Alarm, Page 68
Select "Transmit the following parameters: yes" when making modifications via the
ETS so render the modifications for access codes and alarm settings valid. Previous
settings are then overwritten -including modifications done on the display!
The alarm menu on the display can be secured with an access code that is determined
(or deleted) in the ETS.
If the setting "alarm symbol: image selection" is activated, an image is loaded from the
SD card. The image must be saved to a folder called "festbilder". Please refer to the
chapter
Screen saver, Page 59
2.9. Weekly timer
16 periods may be defined on the weekly timer of the Corlo Touch KNX. Those
periods are then allocated to the internal automatic functions such as, e.g. the timed
closure of blinds. The respective period objects (no. 791 to 806) can be configured as
inputs or outputs, i.d. send to the bus (timer via Corlo Touch KNX, also for other bus
members) or be switched from there (timer function via an external device). If several
displays are used in the system, the timer settings may be done on a device
Use alarm • No
(no alarm functions, all subsequent
parameters hidden)
• Yes
(alarm object active)
Object value for alarm acknowledgement 0 • 1
Transfer the following parameters Yes • No
Access code
(8 digits from 0 to 9)
[free text]
An empty field means that no code query is
done
Alarm action for inputs 1...6:
Flashing back lighting
(is spelt without capitals in the ETS!)
No • Yes
Alarm sound No • Yes
Alarm symbol • Symbol 1...254,
For a list of symbols please refer to
chapter ...
• Image selection
Image number
Only for image selection for alarm symbol
1...65535; 1
Alarm text
Languages 1...6
[free text]
An individual text may be entered for each
language
