141 Additional settings (ETS)
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
6.2.1. Threshold values 1-4
Threshold value:
The threshold value may be set via parameters, i. e. directly in the menu.
ETS: Temperature thresholds > threshold value 1...4
or via communication objects (object no. 922-23/929-30/936-37/943-44).
Threshold value setting via parameter:
Threshold value setting via communications object:
The object value is limited here, and the type of threshold value modification selected
(reception of an absolute value or increase/decrease of the current value).
Switching output:
Set reaction, delay and transmission behaviour for the output
Threshold value setting via • Parameter
• Communication object
Threshold value in 0.1°C -300 ... 800; 200
Hysteresis of the threshold value in % 0 ... 50; 20
The last communicated value should be
retained
• Not
• After voltage recovery
• After voltage recovery and programming
(attention: do not use for first start-up)
Start value
valid till 1st communication
not if value remains intact during
programming
Object value limit (min) in 0.1°C -300 ... 800
Object value limit (max) in 0.1°C -300 ... 800
Type of threshold value change • Absolute value
• Increase / Decrease
Step-by-step
only when increasing/decreasing
0.1°C • ... • 5°C
Hysteresis of the threshold value in % 0 ... 50; 20
Output is at (TV = threshold value) • TV above = 1 | TV - Hyst. below = 0
• TV above = 0 | TV - Hyst. below = 1
• TV above = 1 | TV - Hyst. below = 0
• TV above = 0 | TV - Hyst. below = 1
Delays can be set via objects
(in seconds)
No • Yes
Delay from 0 to 1
if objects are delayed via "yes" objects:
valid till 1st communication
No • 5 s • ... • 2 h
