18 Description

Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.

Store images in the given size in a corresponding folder on the top level of the SD card:

Images for individual image display ("diafix" folder) must have a 4-digit numerical se-

quence so that they can be called up in the ETS and in the menu (0001...9999).

1.8.2. Images for image display

Images can be called up as a stationary display (e. g. welcome screen). In contrast to

the screensaver, the touch function is disabled while a stationary image is displayed.

Images that are to be called up via the "Stationary Image" communication object must

be stored on a micro SD card. In order that the system can recognize the SD card, carry

out a reset in the menu after inserting it

Settings> System > Reset

This is not necessary if the card was inserted before booting the system. The card must

remain in the device.

Store images in the given size in a corresponding folder on the top level of the SD card:

Stationary images must have a 4-digit numerical sequence so that they can be called

up in the ETS and in the menu (0001...9999).

1.8.3. Exchanging images and graphics

For the Corlo Touch KNX 5in display pages, a large number of icons from the area

of security, multimedia, sensors, operation, house, light and air conditioning and drive

control are available and these are stored in the device. However, you can also use pro-

prietary symbol graphics and rotary control graphics.

Images that are shown as icons must be stored on a micro SD card. In order that the

system can recognize the SD card, carry out a reset in the menu after inserting it

Settings> System > Reset

This is not necessary if the card was inserted before booting the system. The card must

remain in the device.

Store images in the given size in a corresponding folder on the top level of the SD card:

Image type Resolution File format Folder name

Images for slide show 800 × 480 pixels .jpg (RGB mode) slideshow

Images for

individual image dis-

play

800 × 480 pixels .jpg (RGB mode) diafix

Image type Resolution File format Folder name

Stationary images 800 × 480 pixels .jpg (RGB mode) fixed image
