19 Description

Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.

Icons must have a 4-digit numerical sequence so that they can be called up in the ETS

and in the menu (0001...9999).

1.9. Connection/control options

For the automatic control of shading, ventilation etc., several different ambient

parameters/measuring values must be provided via the bus. Chapter Overview of

the automatic functions, Seite 19 contains a list of the parameters needed for the

individual automatic functions.

A temperature sensor to capture the room temperature may also be directly connected

to one of the 4 analogue/digital input of the device. Those inputs may also be used

to connect conventional buttons, switches and window contacts.

Date and time should be received at least once a day via the bus (objects no. 7 or

8+9). Object no. 10 serves to request the date and time. The internal device clock de-

viates max. ±3 seconds per day. The alarm function of the Corlo Touch KNX 5in is

only active after the current time has been received from the bus.

1.9.1. Overview of the automatic functions

The Display Corlo Touch KNX 5in has five automatic channels which may be

dedicated to the functions, light, awning, shutter, blind, window, ventilation device and

temperature control (heating/cooling).

General instructions:

• The entire runtime is completed for timed closures (no movement position)

• The movement positions are only settable in the shading and ventilation areas

Lighting:

In order to control the lighting, the ambient parameters/measuring values

•Brightness

•Time

are needed.

• Switching or dimming For dimming, the brightness can be set for ON/OFF.

• Switching on at night and in regular periods. Both may also be combined (AND/

OR). The twilight value is adjustable.

• Automatic resets (time/periods can be set)

Shutters, awnings, blinds:

In order to control the shading, the ambient parameters/measuring values

•Brightness

Image type Resolution File format Folder name

Symbol/small icon 96 × 96 pixels .png icons

Icons for rotary control 316 × 320 pixels .png icons
